PentaGraph
A studio-grade 5-band graphic EQ plugin — a faithful digital recreation of the classic 5-band graphic EQ circuit found in legendary guitar amplifiers and widely recreated as standalone pedals using op-amp gyrator circuits. Calibrated from real hardware measurements.
- Five fixed bands: 80 Hz · 240 Hz · 750 Hz · 2.2 kHz · 6.6 kHz
- ±12 dB boost/cut per band with input & output trim (unity detent)
- Dual-mode: Nominal (clean textbook EQ) and Analog (hardware-calibrated analog modelling with ADAA saturation)
- 15 factory presets for lead, rhythm, clean, jazz, and more
- VST3, AU & Standalone on macOS · VST3 on Windows
Overview
PentaGraph is a digital recreation of the iconic 5-band graphic EQ circuit found in legendary guitar amplifiers and widely recreated as standalone pedals using op-amp gyrator circuits. Rather than a generic parametric EQ with similar frequency points, PentaGraph was engineered from the ground up to reproduce the topology, interaction, and saturation behaviour of the original analog circuit.
The result is an EQ that feels like the real thing: true band independence, the characteristic "V-curve" scoop, gain-dependent Q narrowing, and subtle op-amp saturation when pushed.
PentaGraph operates in two modes, selectable via the Analog Modeling toggle in the settings (cog) menu:
- Nominal mode (default) — uses the pedal’s published frequency labels (80 / 240 / 750 / 2.2k / 6.6k) and clean textbook filtering with no saturation. Each band’s Q is user-adjustable (range 0.3–6.0, default 0.667), so you can dial the EQ from broad and musical to surgical and notch-like. Ideal for general-purpose EQ duties.
- Analog mode — uses studio-calibrated centre frequencies, calibrated per-band Q values, nonlinear gain mapping, and dual-stage ADAA saturation (wrapped in 2× IIR oversampling) to faithfully reproduce the real hardware’s response. The user Q controls are bypassed in this mode in favour of the measured values.
Analog Modeling is a fully automatable parameter and is saved and restored with presets, so factory and user presets can each specify which mode to use.
Interface
The workbench-style faceplate presents five band sliders, a real-time frequency-response curve showing the composite EQ shape with a live spectrum analyser drawn behind it, and IO ring meters that animate with the audio thread.
Each band exposes a compact Q slider beneath its gain fader; you can also adjust Q by mouse-wheeling directly over the band’s point on the curve display, or via host automation. The preset bar groups settings (including the Analog Modeling toggle) into a tidy section-organised popup, and band points on the curve respond with smooth 120 ms eased transitions on hover and active states.
Key Features
- Parallel Summing Topology: Each band filters the dry input independently and the contributions are summed — exactly as in the analog circuit's op-amp summing stage. This preserves true band independence, fundamentally different from cascading five peaking biquads in series.
- Dual-Mode Operation: Switch between Nominal (clean, textbook EQ with published frequencies and user-adjustable per-band Q) and Analog (hardware-calibrated frequencies, calibrated per-band Q, nonlinear gain mapping, and analog saturation) via the settings menu.
- User-Adjustable Per-Band Q (Nominal Mode): Each band has its own Q control (0.3–6.0, default 0.667), editable via the slider under each fader, by mouse-wheeling over the band’s point on the curve, or via host automation — dial each band from broad and musical to surgical and notch-like.
- Hardware-Calibrated Response: All centre frequencies, Q values, and gain mappings were derived from studio measurements of a real 5-band gyrator EQ pedal (48 kHz / 24-bit WAV via MOTU interface, spectral division with 1/6-octave smoothing). Calibration also identified that Band 1 is a low shelf and Band 5 is a high shelf, with Bands 2–4 as wide peaking filters.
- Gain-Dependent Q (Analog Mode): At extreme boost or cut settings, the effective Q narrows smoothly, just like the analog circuit. At ±12 dB the effective Q is ~1.36× the base Q — subtle but musically significant.
- Dual-Stage ADAA Saturation with 2× Oversampling (Analog Mode): Per-band saturation models per-gyrator op-amp headroom, while post-summing saturation models the summing amplifier. Both use first-order Antiderivative Anti-Aliasing with
tanhsoft clipping, wrapped in 2× IIR oversampling (~43 dB image rejection, ~41 dB reduction in naive-tanhaliasing) for clean harmonics with zero reported latency. Per-band drive is envelope-modulated (attack ~1 ms, release ~50 ms) and bypassed entirely at low gain settings for zero overhead. - Pedal-Style Gain Staging: Input and output trims (−40 to +6 dB) with unity detent at 0 dB, so you can place PentaGraph like an FX-loop EQ. Drive the input trim to push the saturation stages for more analog character.
- 15 Factory Presets: From the iconic Classic V scoop to Djent Focus, Jazz Roll-Off, Fuzz Friend, and more — with full user preset management (save, rename, delete).
- Automation-Safe & Efficient: Zero heap allocations on the audio thread, no zipper noise (15–20 ms parameter smoothing), stable across 44.1–192 kHz sample rates, no denormals or NaN propagation.
- Zero-Latency Processing: No latency added to your signal chain. Suitable for tracking, mixing, and live use.
Controls
| Control | Range | Description |
|---|---|---|
| 80 Hz | ±12 dB | Low-end thump and sub control |
| 240 Hz | ±12 dB | Low-mid body and warmth |
| 750 Hz | ±12 dB | Mid focus: the classic scoop frequency |
| 2.2 kHz | ±12 dB | Upper-mid attack and presence |
| 6.6 kHz | ±12 dB | Presence, air, and top-end sparkle |
| Per-band Q (×5) | 0.3 – 6.0 | Bandwidth control per band (Nominal mode only); default 0.667. Editable via the slider under each fader, mouse-wheel over the curve point, or host automation. |
| Input Trim | −40 to +6 dB | Unity detent at 0 dB; drives saturation when raised |
| Output Trim | −40 to +6 dB | Unity detent at 0 dB; final level control |
| Analog Modeling | On / Off | Cog menu toggle; switches between Nominal and Analog modes. Fully automatable and saved with presets. |
| Bypass | On / Off | Power icon in top nav bar; bypasses EQ (trims remain active) |
Double-click any gain or trim control to reset it to 0 dB. Double-click a Q control to reset it to 0.667.
Factory Presets
PentaGraph ships with 15 factory presets. All presets leave Input Trim and Output Trim at 0 dB.
| Preset | Analog | Description |
|---|---|---|
| Init | Off | Flat: all bands at 0 dB |
| Classic V | On | The iconic V-curve with analog modeling: calibrated frequencies, saturation, and Q narrowing |
| Lead | On | Upper-mid and presence emphasis with analog modeling for authentic lead tones |
| Solo Push | Off | Mid-forward bump for solos that need to cut through a mix |
| Tight Rhythm | Off | Scooped but controlled: tight palm mutes and modern metal rhythm |
| Chunk Rhythm | Off | Mild V-curve with low-end weight for chunky rhythm tones |
| Djent Focus | Off | Aggressive low cut with upper-mid attack for modern djent/prog |
| Bass Contour | Off | Enhanced low end with gentle mid scoop for bass guitar or low tunings |
| Fuzz Friend | Off | Tames low-end mud and adds mid focus for pairing with fuzz pedals |
| Warm Clean | Off | Rounded highs and a touch of low-mid warmth for clean tones |
| Sparkle Clean | Off | Bright and airy clean tone with upper-mid shimmer |
| Acoustic Strum | Off | Reduced boominess with presence lift for acoustic or piezo pickups |
| Jazz Roll-Off | Off | Low and high rolloff with mid focus for warm jazz voicings |
| Fizz Tamer | Off | Subtle presence cut to tame harsh or fizzy high-gain amp sims |
| Bedroom Loudness | Off | Fletcher-Munson-inspired boost for full-sounding low-volume playing |
Plugin Formats & Compatibility
| Format | macOS | Windows |
|---|---|---|
| VST3 | ✓ | ✓ |
| AU (Audio Unit) | ✓ | — |
| Standalone | ✓ | — |
Compatible with any VST3- or AU-compatible DAW including Logic Pro, Ableton Live, Reaper, Studio One, Cubase, FL Studio, and more.
System Requirements
macOS
- macOS 10.13 (High Sierra) or later
- 64-bit Intel or Apple Silicon (Universal Binary — runs natively on both)
- 4 GB RAM (8 GB recommended)
- ~50 MB free disk space
- Screen resolution of 1280 × 720 or higher
Windows
- Windows 10 (version 1903 / build 18362) or later, 64-bit only
- x86-64 (AMD64) processor; ARM64 via emulation
- 4 GB RAM (8 GB recommended)
- ~50 MB free disk space
- Screen resolution of 1280 × 720 or higher
